DIMENSIONS
| Max. Working Height | 7.60m/24ft 11in |
| Max. Platform Height | 5.60m/18ft 8in |
| Max. Horizontal Reach   | / |
| Up and Over Height   | / |
| Overall Length    | 1.60m/5ft 3in |
| Overall Width   | 0.80m/2ft 7in |
| Overall Height   | 1.99m/6ft 6in |
| Platform Size (Length×Width)   | 1.00m×0.76m/3ft 3in×2ft 6in |
| Platform Extension Size | 0.50m/1ft 8in |
| Ground Clearance(Stowed)Â Â Â Â | 0.06m/2in |
| Ground Clearance(Raised)Â Â Â | 0.014m/1in |
| Wheelbase    | 1.21m/4ft |
| Turning Radius (Inside/Outside)Â Â Â Â | 0.60m/1.80m / 2ft/5ft 11in |
| Tyres   | φ230×100mm |
Performance
| S.W.LÂ Â Â Â Â | 227kg/500lb |
| S.W.L On Extension | 113kg/249lb |
| Max. Occupants (Inside/Outside)Â Â Â Â | 1/0 |
| Gradeability    | 25% |
| Max. Working Slope     | X-1.5°/Y-3°/ X-1.5°/Y-3° |
| Turret Rotation   | / |
| Jib Movement    | / |
| Travel Speed (Stowed)Â Â Â | 3.6km/h / 2.20mph |
| Travel Speed(Raised)Â Â Â Â | 0.5km/h / 0.30mph |
| Up/Down Speed    | 32/32sec |
Weight
| Overall Weight | 1380kg/3042lb |
Power
| Battery | 2×12V/115Ah |
| Integrated Charger   | 24V/15A |
| Driving Motor    | 2×24V/0.68kW |
| Lifting Motor     | 24V/1.4kW |
